    ASTM A240 UNS S32205/S31803 2205 Duplex Stainless Plate Width 1250mm 1500mm 2000mm

    Ask Lasest Price
    Brand Name : TISCO POSCO BAOSTEEL
    Model Number : 2205 / 1.4462 / UNS S32205 / UNS S31803
    Certification : ISO
    Price : 2500-3500 USD/Ton
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    MOQ : 1 Ton
    • Product Details
    • Company Profile

    ASTM A240 UNS S32205/S31803 2205 Duplex Stainless Plate Width 1250mm 1500mm 2000mm

    ASTM A240 UNS S32205/S31803 2205 Duplex Stainless Plate Width 1250mm 1500mm 2000mm


    Products Specification


    Products Nameduplex stainless steel plate
    Grade2205 / S31803 / S32205 / 1.4462
    ThicknessCold Rolled 0.6 - 3.0mm , Hot Rolled 3.0 - 80.0mm
    Width1000mm 1219mm 1500mm 1800mm 2000mm
    Standard Size1000*2000mm 1219*2438mm 1500*6000mm 1800*6000mm 2000*6000mm or cutting as request
    BrandPOSCO TISCO BAOSTEEL JISCO ESS
    Other Grade304 316L 309S 310S 321 347 2507 904L 254SMO.etc
    ServiceCutting

    Chemical Composition (%) of 2205 Duplex Stainless Steel Plate
    CMnSiPSCrMoNiN
    2205 (S31803)0.032.01.00.030.0221.0- 23.02.5-3.54.5-6.50.08-0.20
    2205 (S32205)0.032.01.00.030.0222.0-23.03.0-3.54.5-6.50.14-0.20
    Mechanical Properties of 2205 Duplex Stainless Steel Plate
    GradeTensile Strength ksi (min)Yield Strength 0.2% ksi (min)Elongation %Hardness (HB) MAX
    2205906525217

    2205 Duplex Stainless Steel Equivalent Standards:

    • ASTM/ASME: A240 UNS S32205/S31803
    • EURONORM: 1.4462 X2CrNiMoN 22.5.3
    • AFNOR: Z3 CrNi 22.05 AZ
    • DIN: W.Nr 1.4462

    Standard Size of our 2205 Duplex Stainless Steel Plate in Stock


    Cold Rolled 2205 duplex stainless steel sheet
    0.4*1219*2438mm0.5*1219*2438mm0.6*1219*2438mm0.8*1219*2438mm1.0*1219*2438mm
    1.2*1219*2438mm1.5*1219*2438mm2.0*1219*2438mm2.5*1219*2438mm3.0*1219*2438mm
    Hot Rolled 2205 duplex stainless steel plate
    3.0*1500*6000mm4.0*1500*6000mm5.0*1500*6000mm6.0*1500*6000mm8.0*1500*6000mm
    10.0*1500*6000mm12.0*1500*6000mm14.0*1500*6000mm16.0*1500*6000mm20.0*1500*6000mm
    6.0*2000*6000mm8.0*2000*6000mm10.0*2000*6000mm12.0*2000*6000mm14.0*2000*6000mm
    16.0*2000*6000mm

    Alloy 2205 (UNS S32305/S31803) is a 22% chromium, 3% molybdenum, 5-6% nickel, nitrogen alloyed duplex stainless steel plate with high general, localized, and stress corrosion resistance properties in addition to high strength and excellent impact toughness.

    Alloy 2205 duplex stainless steel plate provides pitting and crevice corrosion resistance superior to 316L or 317L austenitic stainless steels in almost all corrosive media. It also has high corrosion and erosion fatigue properties as well as lower thermal expansion and higher thermal conductivity than austenitic.


    2205 Duplex Stainless Steel Plate Applications:

    • Chemical processing, transport and storage – pressure vessels, tanks, piping, and heat exchangers
    • Oil and gas exploration and processing equipment – piping, tubing, and heat exchangers
    • Marine and other high chloride environments
    • Effluent scrubbing systems
    • Pulp and paper industry – digesters, bleaching equipment, and stock-handling systems
    • Cargo tanks for ships and trucks
    • Food processing equipment
    • Biofuels plants
