    Heat Resistant Alloy 1.4828 Stainless Steel Sheet Plate Coils AISI309S SS Sheet EN10095

    Ask Lasest Price
    Brand Name : TISCO BAOSTEEL
    Model Number : 1.4828
    Certification : ISO
    Price : 2100-2500 USD/Ton
    Payment Terms : T/T, Western Union
    Supply Ability : 20Ton per week
    Delivery Time : 5 - 12 days based on the quantity
    • Product Details
    • Company Profile

    Heat Resistant Alloy 1.4828 Stainless Steel Sheet Plate Coils AISI309S SS Sheet EN10095

    Heat Resistant Alloy 1.4828 Stainless Steel Sheet Plate Coils AISI309S SS Sheet EN10095

    Products Specification


    Product name1.4828 Stainless steel Sheet / plate
    StandardEN 10095:1999
    Thickness0.4 - 20.0mm
    Width1219, 1500mm, or as your requirements
    Length2438, 3000,6000mm, or as your requirements
    MOQ1MT
    Surface2B NO.1
    Packingstandard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
    Similar Grade We Can Supply321, 310S
    Delivery TimeAbout 5-7 days after receive the deposit.

    Regular Size of 1.4828 Stainless Steel Sheet / Plate in Stock


    0.4*1219*2438mm0.5*1219*2438mm0.6*1219*2438mm0.8*1219*2438mm
    1.0*1219*2438mm1.2*1219*2438mm1.5*1219*2438mm2.0*1219*2438mm
    2.5*1219*2438mm3.0*1219*2438mm4.0*1500*6000mm5.0*1500*6000mm
    6.0*1500*6000mm8.0*1500*6000mm10.0*1500*6000mm12.0*1500*6000mm
    14.0*1500*6000mm16.0*1500*6000mm20.0*1500*6000mm

    austenitic stainless steel 1.4828 AISI 309 UNS S30900 is a steel suitable for high-temperature applications. With a maximum service temperature in air of 1,000°C in fact, this heat-resistant austenitic stainless steel offers excellent corrosion resistance to oxidation and carbonization. Its characteristics make it ideal for making industrial furnace and boiler components, expansion tubes and bellows, electrical heating elements, aeronautical engineering, and automotive exhaust systems.

    CHEMICAL COMPOSITION Werkstoff 1.4828 AISI 309 UNS S30900


    ElementMinMax
    C0.20
    S0.015
    P0.045
    Yes1.502.00
    Mn2.00
    Cr19.0021.00
    Ni11.0013.00
    N0.11

    MECHANICAL FEATURES 1.4828 AISI 309 UNS S30900


    MaterialLeagueRm min (MPa)Rp 0.2 min (MPa)A% minZ% minHardness max (HB)
    AISI 3091.4828500 – 7502303055220

    PHYSICAL PROPERTIES1.4828 AISI 309 UNS S30900


    • Specific gravity: 7.9 kg/dm³ at 20°C
    • Modulus of elasticity: 206,000 N/mm² at 20°C
    • Thermal conductivity: 15 W/m.K at 20°C
    • Specific heat: 500 J/g.K at 20°C
    • Coefficients of linear expansion: 16.5 (20° – 200°C), 17.5 (20° – 400°C), 18.0 (20° – 600°C)
    • Electrical resistivity: 0.85 Ω mm²/m at 20°C
    • Amagnetic

    CORRESPONDENCE AND SPECIFICATIONS 1.4828 AISI 309 UNS S30900


    • EN 10095: X15 Cr Ni Si 20-12
    • W: 1.4828
    • JIS: SUH309
    • AISI: 309
    • UNS: S30900

    Applications of 1.4828 Stainless Steel

    • Industrial furnaces and boiler components
    • Tubes and expansions bellows
    • Electrical heating elements
    • Aeronautical engineering
    • Automotive exhaust systems
